商品描述
本店商品均不含税点金额，如需开发票请咨询客户添加税点，如直接备注开票未咨询客服＋税点的，本店有权不开发票。
AC100-240V 国外输入电压
AC座：国内外双插
DC规格：充电器12V1A 8.4V1A
适配器：12V（0-6A) 8.4V (0-3A) 等其它参数可定制
质保期：2年
毛重：0.33
认证：CCC CE PSE UL KC
包装规格：50PCS/ 箱
DC线长：1M 1.2M 1.5M等
DC头规格：5521 5525 M12 M16等
电路保护：过压 过流 过温 短路等保护
产品优势：苹果外观，纹路细可在上面加激光LOGO 真实过安规EMC EMI LVD.散热好 功率足 可反复充电温升低，市场上同类产品往往温度高不能反复充电。比市场上同等功率的用料更扎实 性价比高。
| Product Description/产品参数 | ||
| INPUT/输入特性 | voltage range | 100-240VAC |
| frequency range | 47-63Hz | |
| standby power | 1A | |
| efficiency | DOE VI /V | |
| AC input current | A max at 230VAC at full load | |
| Irush current | 30A Max. @110Vac/60Hz | |
| 60A Max. @230Vac/50Hz | ||
| OUTPUT/输出特性 | DC voltage range | 8.4V/4.2V/5V/9V/12.6V/16.8V/18V/20V/26V max |
| voltage range | ±5% | |
| load current | 500MA/1A/1.5A/2A max | |
| range power | 0-12w max | |
| voltage tolerance | ±5% | |
| line regulation | ±1% | |
| load regulation | ±5% | |
| AC Plug/AC插头 | US/美 EU/欧 | UK/英 |
| AU/澳 JP/日本 | Other/其它国家 | |
| KOREA/韩国 CHINA/中国 | ||
| DC Plug straight Lshape/输出DC头 | 5.5*2.1 | Mini USB MICRO |
| 5.5*2.5 | Crocodile clip red+ black- | |
| 4.0*1.7 | AVIATION HEAD | |
| 3.5*1.35 | Double and line | |
| TYPE-C | lotus skill | |
| 2.0*0.7 | other as your requirment | |
| DC CORD/输出线 | 1m/1.2m /1.5m / 1.8m /2m /3m | other as your requirment |
| PROTECTION | over voltage protection | |
| over current protection | ||
| short circuit | ||
| SAFETY APPROVALS/认证标准 | UL62368/ UL60950/ UL1310/ CE/ GS/ SAA/ KC KCC/ PSE/ RCM | |
| MTBF/使用时间 | 50000 hours | |
| WARRANTY/质保 | 36 months | |
| LED indicator light/指示灯 | unloaded green light /red light | |
operating temperature 使用环境 | 0°c-40°c | storage temperature :-20c-85°c |
| protection | With short-circut protection | over current protection |
| test/带 载 | 100 full load burn-in test | |
| PACKAGE/包装 | PE bag and white box | |
| Carton Size/箱尺寸 | 46*39*26cm | |
